TPS7H5005-SEP, TPS7H5006-SEP, TPS7H5007-SEP, TPS7H5008-SEP
www.ti.com
SLVSGG1 – FEBRUARY 2022
13.1 Mechanical Data
PACKAGE OUTLINE
PW0024A
TSSOP - 1.2 mm max height
S
C
A
L
E
2
.
0
0
0
SMALL OUTLINE PACKAGE
SEATING
PLANE
C
6.6
6.2
TYP
PIN 1 INDEX AREA
A
0.1 C
22X 0.65
24
1
2X
7.15
7.9
7.7
NOTE 3
12
13
0.30
24X
4.5
4.3
NOTE 4
0.19
1.2 MAX
B
0.1
C A B
0.25
GAGE PLANE
0.15
0.05
(0.15) TYP
SEE DETAIL A
0.75
0.50
0 -8
A
20
DETAIL A
TYPICAL
4220208/A 02/2017
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not
exceed 0.15 mm per side.
4. This dimension does not include interlead flash. Interlead flash shall not exceed 0.25 mm per side.
5. Reference JEDEC registration MO-153.
