EXAMPLE STENCIL DESIGN
PW0024A
TSSOP - 1.2 mm max height
SMALL OUTLINE PACKAGE
24X (1.5)
SYMM
(R0.05) TYP
1
24
24X (0.45)
22X (0.65)
SYMM
12
13
(5.8)
SOLDER PASTE EXAMPLE
BASED ON 0.125 mm THICK STENCIL
SCALE: 10X
4220208/A 02/2017
NOTES: (continued)
8. Laser cutting apertures with trapezoidal walls and rounded corners may offer better paste release. IPC-7525 may have alternate
design recommendations.
9. Board assembly site may have different recommendations for stencil design.
