Bits
Field Name
Description
Type
Reset
7
ALARM_PM_NAM
Only used in PM_AM mode for alarm programmation (otherwise it is set
RW
0
to 0)
0 is AM
1 is PM
6
Reserved
Reserved bit
RO
R returns
0s
0
5:4
3:0
ALARM_HOUR1
ALARM_HOUR0
Second digit of alarm programmation for hours(range is 0 up to 2)
First digitof alarm programmation for hours (range is 0 up to 9)
RW
RW
0x0
0x0
Table 25. ALARM_DAYS_REG
Address Offset
Physical Address
Description
Type
0x0B
Instance
RTC register for alarm programmation for days
RW
7
6
5
4
3
2
1
0
Reserved
ALARM_DAY1
ALARM_DAY0
Bits
Field Name
Description
Type
Reset
7:6
Reserved
Reserved bit
RO
0x0
R Special
5:4
3:0
ALARM_DAY1
ALARM_DAY0
Second digit of alarm programmation for days (range is 0 up to 3)
First digit of alarm programmation for days (range is 0 up to 9)
RW
RW
0x0
0x1
Table 26. ALARM_MONTHS_REG
Address Offset
Physical Address
Description
Type
0x0C
Instance
RTC register for alarm programmation for months
RW
7
6
5
4
3
2
1
0
Reserved
ALARM_MONTH0
Bits
Field Name
Reserved
Description
Type
Reset
7:5
Reserved bit
RO
R returns
0s
0x0
4
ALARM_MONTH1
ALARM_MONTH0
Second digit of alarm programmation for months (range is 0 up to 1)
First digit of alarm programmation for months (range is 0 up to 9)
RW
RW
0
3:0
0x1
Table 27. ALARM_YEARS_REG
Address Offset
Physical Address
Description
Type
0x0D
Instance
RTC register for alarm programmation for years
RW
