TPS65910, TPS65910A, TPS65910A3, TPS659101, TPS659102, TPS659103
TPS659104, TPS659105, TPS659106, TPS659107, TPS659108, TPS659109
www.ti.com
SWCS046N –MARCH 2010–REVISED APRIL 2012
7
6
5
4
3
2
1
0
Reserved
DAY1
DAY0
MONTH0
YEAR0
Bits
Field Name
Description
Type
Reset
7:6
Reserved
Reserved bit
RO
R returns
0s
0x0
5:4
3:0
DAY1
DAY0
Second digit of days (range is 0 up to 3)
First digit of days (range is 0 up to 9)
RW
RW
0x0
0x1
Table 19. MONTHS_REG
Address Offset
Physical Address
Description
Type
0x04
Instance
RTC register for months
RW
7
6
5
4
3
2
1
0
Reserved
MONTH1
Bits
Field Name
Description
Type
Reset
7:5
Reserved
Reserved bit
RO
R returns
0s
0x0
4
MONTH1
MONTH0
Second digit of months (range is 0 up to 1)
First digit of months (range is 0 up to 9)
RW
RW
0
3:0
0x1
Table 20. YEARS_REG
Address Offset
Physical Address
Description
Type
0x05
Instance
RTC register for day of the week
RW
7
6
5
4
3
2
1
0
YEAR1
Bits
7:4
Field Name
Description
Type
RW
Reset
0x0
YEAR1
YEAR0
Second digit of years (range is 0 up to 9)
First digit of years (range is 0 up to 9)
3:0
RW
0x0
Table 21. WEEKS_REG
Address Offset
Physical Address
Description
Type
0x06
Instance
RTC register for day of the week
RW
7
6
5
4
3
2
1
0
Reserved
WEEK
Copyright © 2010–2012, Texas Instruments Incorporated
Submit Documentation Feedback
55
Product Folder Link(s): TPS65910 TPS65910A TPS65910A3 TPS659101 TPS659102 TPS659103 TPS659104
TPS659105 TPS659106 TPS659107 TPS659108 TPS659109
