TPS54531
SLVSBI5 –MAY 2013
www.ti.com
These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam
during storage or handling to prevent electrostatic damage to the MOS gates.
DESCRIPTION CONTINUED
For additional design needs, see:
TPS54231
2A
TPS54232
2A
TPS54233
2A
TPS54531
5A
TPS54332
3.5A
IO(Max)
Input Voltage Range
Switching Freq. (Typ)
Switch Current Limit (Min)
Pin/Package
3.5V - 28V
570kHz
2.3A
3.5V - 28V
1000kHz
2.3A
3.5V - 28V
285kHz
2.3A
3.5V - 28V
570kHz
5.5A
3.5V - 28V
1000kHz
4.2A
8SOIC
8SOIC
8SOIC
8SO PowerPAD™ 8SO PowerPAD™
ORDERING INFORMATION(1)
TJ
PACKAGE
SWITCHING FREQUENCY
PART NUMBER(2)
–40°C to 150°C
8 pin SOIC PowerPAD™
570 kHz
TPS54531DDA
(1) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
web site at www.ti.com.
(2) The DDA package is also available taped and reeled. Add an R suffix to the device type (i.e., TPS54531DDAR). See applications
section of data sheet for layout information.
ABSOLUTE MAXIMUM RATINGS(1)
over operating free-air temperature range (unless otherwise noted)
VALUE
–0.3 to 30
–0.3 to 6
38
UNIT
VIN
EN
BOOT
Input Voltage
V
VSENSE
–0.3 to 3
–0.3 to 3
–0.3 to 3
8
COMP
SS
BOOT-PH
Output Voltage
Source Current
Sink Current
PH
–0.6 to 30
–5
V
PH (10 ns transient from ground to negative peak)
EN
100
μA
mA
μA
A
BOOT
100
VSENSE
10
PH
Current Limit
Current Limit
100
VIN
A
COMP
μA
SS
200
Electrostatic
Discharge
Human body model (HBM)
Charged device model (CDM)
2
kV
kV
°C
°C
1
Operating Junction Temperature
Storage Temperature
–40 to 150
–65 to 150
(1) Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
2
Submit Documentation Feedback
Copyright © 2013, Texas Instruments Incorporated
Product Folder Links: TPS54531
