TPS54332
SLVS875B –JANUARY 2009–REVISED FEBRUARY 2012
www.ti.com
VOUT
VOUT
1 V/div
20 mV/div
5 V/div
PH
VIN
5 V/div
t - Time - 2 ms/div
t - Time - 2 ms/div
Figure 22. TPS54332 Start Up
Figure 23. TPS54332 Output Ripple During Eco-
mode™ Operation
SPACER
REVISION HISTORY
Changes from Original (January 2009) to Revision A
Page
•
•
Added a new table to the Description - For additional design needs ................................................................................... 2
Changed the ABSOLUTE MAXIMUM RATINGS table, Input Voltage - EN pin max value From: 5V to 6V ........................ 2
Changes from Revision A (march 2010) to Revision B
Page
•
•
Deleted Swift™ from the data sheet title .............................................................................................................................. 1
Deleted feature Item: For SWIFT™ Documentation, See the TI Website at www.ti.com/swift ............................................ 1
20
Submit Documentation Feedback
Copyright © 2009–2012, Texas Instruments Incorporated
Product Folder Link(s): TPS54332
