TPS2041B-Q1
TPS2042B-Q1
TPS2051B-Q1
www.ti.com
SLVS782A –NOVEMBER 2007–REVISED JUNE 2010
DEVICE INFORMATION
Terminal Functions (TPS2041B)
TERMINAL
I/O
DESCRIPTION
NAME
EN
NO.
4
I
Enable input, logic low turns on power switch
GND
IN
2
Ground
5
I
Input voltage
OC
3
O
O
Overcurrent, open-drain output, active low
Power-switch output
OUT
1
Functional Block Diagram (TPS2041B)
(See Note A)
CS
OUT
IN
Charge
Pump
Current
Limit
EN
Driver
OC
UVLO
Deglitch
Thermal
Sense
GND
A. CS = Current sense
