TPS2061, TPS2062, TPS2063
TPS2065, TPS2066, TPS2067
www.ti.com
SLVS490B–DECEMBER 2003–REVISED DECEMBER 2004
These devices have limited built-in ESD protection. The leads should be shorted together or the device
placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
AVAILABLE OPTION AND ORDERING INFORMATION
RECOMMENDED
MAXIMUM
CONTINUOUS
LOAD CURRENT
TYPICAL
SHORT-CIRCUIT
CURRENT LIMIT
AT 25°C
PACKAGED
DEVICES
(1)
NUMBER OF
SWITCHES
TA
ENABLE
MSOP (DGN)
SOIC(D)
Active low
Active high
Active low
Active high
Active low
Active high
TPS2061DGN
TPS2061D
TPS2065D
TPS2062D
TPS2066D
TPS2063D
TPS2067D
Single
Dual
TPS2065DGN
TPS2062DGN
-40°C to 85°C
1 A
1.5 A
TPS2066DGN
-
-
Triple
(1) The package is available taped and reeled. Add an R suffix to device types (e.g., TPS2062DR).
LEAD (PB-FREE) ORDERING INFORMATION
TA
SOIC(D)
STATUS(1)
ECO-STATUS(2)
MSOP (DGN)
TPS2061DGNG4
TPS2062DGNG4
TPS2065DGNG4
TPS2066DGNG4
STATUS(1)
Active
ECO-STATUS(2)
TPS2061DG4
TPS2062DG4
TPS2065DG4
TPS2066DG4
Active
Active
Active
-40°C to 85°C
Green
Green
Active
Active
Active
Active
(1) The marketing status values are defined as follows:
•
•
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend
using this part in a new design.
•
•
PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued production of the device.
(2) Eco-Status information - Additional details including specific material content can be accessed at www.ti.com/leadfree
•
•
N/A: Not yet available Lead (Pb)-Free, for estimated conversion dates go to www.ti.com/leadfree.
Pb-Free: TI defines “Lead (Pb)-Free” or “Pb-Free” to mean RoHS compatible, including a lead concentration that does not exceed
0.1% of total product weight, and, if designed to be soldered, suitable for use in specified lead-free soldering processes.
•
Green: TI defines “Green” to mean Lead (Pb)-Free and in addition, uses package materials that do not contain halogens, including
bromine (Br), or antimony (Sb) above 0.1% of total product weight.
2
