6 Specifications
6.1 Absolute Maximum Ratings
Over operating free-air temperature range (unless otherwise noted)(1)
MIN
MAX
28
UNIT
V
Maximum continuous supply voltage, VBB
Load dump voltage, VLD
Reverse Polarity Voltage
Enable pin current, IEN
ISO16750-2:2010(E)
36
V
Maximum duration 3 minutes
V
–18
–1
20
7
mA
V
Enable pin voltage, VEN
Diagnostic Enable pin current, IDIA_EN
Diagnostic Enable pin voltage, VDIA_EN
Sense pin current, ISNS
–1
20
7
mA
V
–1
–1
10
5.5
10
7
mA
V
–100
–1
Sense pin voltage, VSNS
Latch pin current, ILATCH
Latch pin voltage, VLATCH
FLT pin current, IFLT
mA
V
–1
–1
10
7
mA
V
–30
–0.3
FLT pin voltage, VFLT
Reverse ground current, IGND
Storage temperature, Tstg
VBB < 0 V
mA
°C
–50
150
–65
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under
Recommended Operating Conditions. Exposure to absolute maximum rated conditions for extended periods may affect device
reliability.
6.2 ESD Ratings
VALUE
UNIT
Human-body model (HBM), per AEC
Q100-002 Classification Level H2(2)
All pins except VS and VOUT
VS and VOUT
±2000
Electrostatic
discharge(1)
Human-body model (HBM), per AEC
Q100-002 Classification Level H3A(2)
V(ESD)
±4000
±750
V
Charged-device model (CDM), per AEC Q100-011
Classification Level C5
All pins
(1) All ESD strikes are with reference from the pin mentioned to GND
(2) AEC-Q100-002 indicates that HBM stressing shall be in accordance with the ANSI/ESDA/JEDEC JS-001 specifications.
6.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted) (1)
MIN
3.5
MAX
18
UNIT
VVBB_NOM
VVBB_EXT
VVBB_SC
VEN
Nominal supply voltage (1)
Extended supply voltage(2)
Short circuit supply voltage capability
Enable voltage
V
V
2.6
28
28
V
5.5
5.5
5.5
7
V
–1
–1
VDIA_EN
VLATCH
VSNS
Diagnostic Enable voltage
Latch voltage
V
V
–1
Sense voltage
V
–1
TA
Operating free-air temperature
125
°C
–40
(1) All operating voltage conditions are measured with respect to device GND
