TMS570LS3137
www.ti.com
SPNS162.–SEPTEMBER 2011
2.4.2.13 Embedded Trace Macrocell for Cortex-R4F CPU (ETM-R4F)
Table 2-35. Embedded Trace Macrocell for Cortex-R4F CPU (ETM-R4F)
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
337
ZWT
ETMTRACECLKIN/EXTCLKIN2
R9
R10
R11
R12
R13
J15
H15
G15
F15
E15
E14
E9
Input Pull Down Fixed, 20uA
ETM Trace Clock Input
ETM Trace Clock Output
ETM trace control
ETM data
ETMTRACECLKOUT
Output Pull Down
Output Pull Down
-
-
ETMTRACECTL
ETMDATA[0]
ETMDATA[01]
ETMDATA[02]
ETMDATA[03]
ETMDATA[04]
ETMDATA[05]
ETMDATA[06]
ETMDATA[07]
ETMDATA[08]/EMIF_ADDR[5]
ETMDATA[09]/EMIF_ADDR[4]
ETMDATA[10]/EMIF_ADDR[3]
ETMDATA[11]/EMIF_ADDR[2]
ETMDATA[12]/EMIF_BA[0]
ETMDATA[13]/EMIF_nOE
ETMDATA[14]/EMIF_nDQM[1]
ETMDATA[15]/EMIF_nDQM[0]
ETMDATA[16]/EMIF_DATA[0]
ETMDATA[17]/EMIF_DATA[1]
ETMDATA[18]/EMIF_DATA[2]
ETMDATA[19]/EMIF_DATA[3]
ETMDATA[20]/EMIF_DATA[4]
ETMDATA[21]/EMIF_DATA[5]
ETMDATA[22]/EMIF_DATA[6]
ETMDATA[23]/EMIF_DATA[7]
ETMDATA[24]/EMIF_DATA[8]
ETMDATA[25]/EMIF_DATA[9]
ETMDATA[26]/EMIF_DATA[10]
ETMDATA[27]/EMIF_DATA[11]
ETMDATA[28]/EMIF_DATA[12]
ETMDATA[29]/EMIF_DATA[13]
ETMDATA[30]/EMIF_DATA[14]
ETMDATA[31]/EMIF_DATA[15]
E8
E7
E6
E13
E12
E11
E10
K15
L15
M15
N15
E5
F5
G5
K5
L5
M5
N5
P5
R5
R6
R7
R8
Copyright © 2011, Texas Instruments Incorporated
Device Package and Terminal Functions
33
