TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
Table 6-76. HECC Message Object Registers (continued)
HEX ADDRESS RANGE
01C2 50B0
01C2 50B4
01C2 50B8
01C2 50BC
01C2 50C0
01C2 50C4
01C2 50C8
01C2 50CC
01C2 50D0
01C2 50D4
01C2 50D8
01C2 50DC
01C2 50E0
01C2 50E4
01C2 50E8
01C2 50EC
01C2 50F0
01C2 50F4
01C2 50F8
01C2 50FC
ACRONYM
MOTS12
MOTS13
MOTS14
MOTS15
MOTS16
MOTS17
MOTS18
MOTS19
MOTS20
MOTS21
MOTS22
MOTS23
MOTS24
MOTS25
MOTS26
MOTS27
MOTS28
MOTS29
MOTS30
MOTS31
REGISTER NAME
Message Object Time-Stamp Register for Mailbox 12
Message Object Time-Stamp Register for Mailbox 13
Message Object Time-Stamp Register for Mailbox 14
Message Object Time-Stamp Register for Mailbox 15
Message Object Time-Stamp Register for Mailbox 16
Message Object Time-Stamp Register for Mailbox 17
Message Object Time-Stamp Register for Mailbox 18
Message Object Time-Stamp Register for Mailbox 19
Message Object Time-Stamp Register for Mailbox 20
Message Object Time-Stamp Register for Mailbox 21
Message Object Time-Stamp Register for Mailbox 22
Message Object Time-Stamp Register for Mailbox 23
Message Object Time-Stamp Register for Mailbox 24
Message Object Time-Stamp Register for Mailbox 25
Message Object Time-Stamp Register for Mailbox 26
Message Object Time-Stamp Register for Mailbox 27
Message Object Time-Stamp Register for Mailbox 28
Message Object Time-Stamp Register for Mailbox 29
Message Object Time-Stamp Register for Mailbox 30
Message Object Time-Stamp Register for Mailbox 31
Message Object Time-Out Registers
01C2 5100
01C2 5104
01C2 5108
01C2 510C
01C2 5110
01C2 5114
01C2 5118
01C2 511C
01C2 5120
01C2 5124
01C2 5128
01C2 512C
01C2 5130
01C2 5134
01C2 5138
01C2 513C
01C2 5140
01C2 5144
01C2 5148
01C2 514C
01C2 5150
01C2 5154
01C2 5158
01C2 515C
01C2 5160
01C2 5164
MOTO0
MOTO1
MOTO2
MOTO3
MOTO4
MOTO5
MOTO6
MOTO7
MOTO8
MOTO9
MOTO10
MOTO11
MOTO12
MOTO13
MOTO14
MOTO15
MOTO16
MOTO17
MOTO18
MOTO19
MOTO20
MOTO21
MOTO22
MOTO23
MOTO24
MOTO25
Message Object Time-Out Register for Mailbox 0
Message Object Time-Out Register for Mailbox 1
Message Object Time-Out Register for Mailbox 2
Message Object Time-Out Register for Mailbox 3
Message Object Time-Out Register for Mailbox 4
Message Object Time-Out Register for Mailbox 5
Message Object Time-Out Register for Mailbox 6
Message Object Time-Out Register for Mailbox 7
Message Object Time-Out Register for Mailbox 8
Message Object Time-Out Register for Mailbox 9
Message Object Time-Out Register for Mailbox 10
Message Object Time-Out Register for Mailbox 11
Message Object Time-Out Register for Mailbox 12
Message Object Time-Out Register for Mailbox 13
Message Object Time-Out Register for Mailbox 14
Message Object Time-Out Register for Mailbox 15
Message Object Time-Out Register for Mailbox 16
Message Object Time-Out Register for Mailbox 17
Message Object Time-Out Register for Mailbox 18
Message Object Time-Out Register for Mailbox 19
Message Object Time-Out Register for Mailbox 20
Message Object Time-Out Register for Mailbox 21
Message Object Time-Out Register for Mailbox 22
Message Object Time-Out Register for Mailbox 23
Message Object Time-Out Register for Mailbox 24
Message Object Time-Out Register for Mailbox 25
