3.3.18 Timer Output Selection Register (TOUTPSEL)
The timer output selection is handled within the control register TOUTSEL. The Timer Output Selection Register
is shown in Figure 3-17 and described in Table 3-19.
Figure 3-17
Timer Output Selection Register (TOUTPSEL)
31
10
9
5
4
0
Reserved
TOUTPSEL1
RW,+00001
TOUTPSEL0
RW,+00000
R,+000000000000000000000000
Legend: R = Read only; RW = Read/Write; -n = value after reset
Table 3-19
Timer Output Selection Field Description (TOUTPSEL)
Bit
Field
Description
31-10
9-5
Reserved
Reserved
TOUTPSEL1
Output select for TIMO1
00000: TOUTL0
00001: TOUTH0
00010: TOUTL1
00011: TOUTH1
00100: TOUTL2
00101: TOUTH2
00110: TOUTL3
00111: TOUTH3
01000: TOUTL4
01001: TOUTH4
01010: TOUTL5
01011: TOUTH5
01100: TOUTL6
01101: TOUTH6
01110: TOUTL7
01111: TOUTH7
10000: TOUTL8
10001: TOUTH8
10010: TOUTL9
10011: TOUTH9
10100: TOUTL10
10101: TOUTH10
10110: TOUTL11
10111: TOUTH11
11000: TOUTL12
11001: TOUTH12
11010: TOUTL13
11011: TOUTH13
11100: TOUTL14
11101: TOUTH14
11110: TOUTL15
11111: TOUTH15
4-0
TOUTPSEL0
Output select for TIMO0
00000: TOUTL0
00001: TOUTH0
00010: TOUTL1
00011: TOUTH1
00100: TOUTL2
00101: TOUTH2
00110: TOUTL3
00111: TOUTH3
01000: TOUTL4
01001: TOUTH4
01010: TOUTL5
01011: TOUTH5
01100: TOUTL6
01101: TOUTH6
01110: TOUTL7
01111: TOUTH7
10000: TOUTL8
10001: TOUTH8
10010: TOUTL9
10011: TOUTH9
10100: TOUTL10
10101: TOUTH10
10110: TOUTL11
10111: TOUTH11
11000: TOUTL12
11001: TOUTH12
11010: TOUTL13
11011: TOUTH13
11100: TOUTL14
11101: TOUTH14
11110: TOUTL15
11111: TOUTH15
End of Table 3-19
