7.22 Management Data Input/Output (MDIO)
The management data input/output (MDIO) module implements the 802.3 serial management interface to
interrogate and controls up to 32 Ethernet PHY(s) connected to the device, using a shared two-wire bus. Application
software uses the MDIO module to configure the auto-negotiation parameters of each PHY attached to the GbE
switch subsystem, retrieve the negotiation results, and configure required parameters in the GbE switch subsystem
module for correct operation. The module is designed to allow almost transparent operation of the MDIO interface,
with very little maintenance from the core processor. For more information, see the Gigabit Ethernet (GbE) Switch
Subsystem for KeyStone Devices User Guide in ‘‘Related Documentation from Texas Instruments’’ on page 73.
Table 7-82
See Figure 7-57
MDIO Timing Requirements
No.
Min
Max
Unit
1
2
3
4
5
tc(MDCLK)
tw(MDCLKH)
tw(MDCLKL)
Cycle time, MDCLK
400
180
180
10
ns
ns
ns
ns
ns
ns
Pulse duration, MDCLK high
Pulse duration, MDCLK low
tsu(MDIO-MDCLKH) Setup time, MDIO data input valid before MDCLK high
th(MDCLKH-MDIO)
tt(MDCLK)
Hold time, MDIO data input valid after MDCLK high
Transition time, MDCLK
0
5
End of Table 7-82
Figure 7-57
MDIO Input Timing
MDCLK
2
3
4
5
MDIO
(Input)
Table 7-83
MDIO Switching Characteristics
Parameter
See Figure 7-58
No.
Min
Max
Unit
6
td(MDCLKL-MDIO)
Delay time, MDCLK low to MDIO data output valid
100
ns
End of Table 7-83
Figure 7-58
MDIO Output Timing
1
MDCLK
6
MDIO
(Ouput)
