HPD Pins
The HPD circuits are powered by the 3.3-V VCC supply. This provides maximum VOH = VCC and maximum
VOL= 0.4-V output signals to the SOURCE with a typical 1-kΩ output resistance. An external 1-kΩ resistor is not
needed here. The HPD output of the selected source port follows the logic level of the HPD_SINK input.
Unselected HPD outputs are kept low. When the device is in standby mode, all HPD outputs follow HPD_SINK.
If VOH greater than VCC is desired, then an external circuit as shown in Figure 45 can be used. In this case, the
max VOH can be equal to the 5 V coming from the HDMI source.
5V_Source (5V coming from HDMI source)
VCC/5V_source
VCC
1 kW
1 kW
HPD_SOURCE
1 kW (internal
series resistor)
10 kW
HPD[1:3]
HPD_SINK
TMDS361B
VCC
ON
HPD_SINK
HPD[1:3]
HPD_SOURCE
L
H
X
H
L
L
ON
H
H
OFF
Z
S0387-08
Figure 45. External Circuit to Drive 5-V VOH on HPD[1:3]
Layout Considerations
The high-speed differential TMDS inputs are the most critical paths for the TMDS361B. There are several
considerations to minimize discontinuities on these transmission lines between the connectors and the device:
•
•
•
•
•
Maintain 100-Ω differential transmission line impedance into and out of the TMDS361B.
Keep an uninterrupted ground plane beneath the high-speed I/Os.
Keep the ground-path vias to the device as close as possible to allow the shortest return current path.
Keep the trace lengths of the TMDS signals between connector and device as short as possible.
Keep intra-pair skew (trace length) between the positive and negative TMDS inputs to be matched to within 5
mils (0.005 inches or 0.127 mm).
Using the TMDS361B in Systems With Different CEC Link Requirements
The TMDS361B supports a DTV with up to three HDMI inputs when used in conjunction with a signal-port HDMI
receiver. Figure 46 and Figure 47 show simplified application block diagrams for the TMDS361B in different
DTVs with different consumer electronic control (CEC) requirements. The CEC is an optional feature of the HDMI
interface for centralizing and simplifying user control instructions from multiple audio/video products in an
interconnected system, even when all the audio/video products are from different manufacturers. This feature
minimizes the number of remote controls in a system, as well as reducing the number of times buttons must be
pressed.
