TMDS261
www.ti.com ............................................................................................................................................................................................ SLLS953–DECEMBER 2008
TYPICAL CHARACTERISTICS (continued)
AVCC = 3.3 V, RT = 50 Ω
TP1
TP2
TP3
TMDS261 Test Board
HDMI Cable
Video
Format
TMDS
261
Generator
Figure 22. HDMI Cable Test-Point Configuration
Figure 23. Eye at TP3 (Output of TMDS261) With 20-m,
24-AWG HDMI Cable, 2.25-Gbps Input TMDS data Rate,
Fastest Rise- and Fall-Time Setting on TMDS Outputs
Figure 24. Eye at TP3 (Output of TMDS261) With 20-m,
24-AWG HDMI Cable, 3-Gbps Input TMDS Data Rate,
Fastest Rise- and Fall-Time Setting on TMDS Outputs
Figure 25. Eye at TP3 (Output of TMDS261) With 3-m,
28-AWG HDMI Cable, 3-Gbps Input TMDS Data Rate,
Fastest Rise- and Fall-Time Setting on TMDS Outputs
Figure 26. Eye at TP3 (Output of TMDS261) With 3-m,
28-AWG HDMI Cable, 3-Gbps Input TMDS Data Rate,
Slowest Rise- and Fall-Time Setting on TMDS Outputs
Copyright © 2008, Texas Instruments Incorporated
Submit Documentation Feedback
21
Product Folder Link(s) :TMDS261
