ELECTRICAL CHARACTERISTICS (continued)
TA = +25°C and VS = +2.7 V to +5.5 V (unless otherwise noted).
Boldface limits apply over the specified temperature range, TA = −40°C to +125°C.
TLV3501-Q1
TYP
PARAMETER
CONDITIONS
MIN
MAX
UNIT
POWER SUPPLY
Specified voltage
VS
IQ
+2.7
+5.5
V
V
Operating voltage range
Quiescent current
TEMPERATURE RANGE
Specified range
2.2 to 5.5
3.2
VS = 5 V, VO = High
5
mA
–40
–40
–65
+125
+125
+150
°C
°C
°C
Operating range
Storage range
Thermal resistance
SOT23-6
qJA
200
°C/W
PIN CONFIGURATIONS
SOT23-6(1)
DBV PACKAGE
(TOP VIEW)
-IN
V-
1
2
3
6
5
4
SHDN
OUT
V+
+IN
(1) Pin 1 is determined by orienting the package marking as indicated on the diagram.
