MECHANICAL DATA
DW (R-PDSO-G**)
PLASTIC SMALL-OUTLINE PACKAGE
16 PINS SHOWN
0.050 (1,27)
16
0.020 (0,51)
0.010 (0,25)
M
0.014 (0,35)
9
0.419 (10,65)
0.400 (10,15)
0.010 (0,25) NOM
0.299 (7,59)
0.291 (7,39)
Gage Plane
0.010 (0,25)
1
8
0°–8°
0.050 (1,27)
0.016 (0,40)
A
Seating Plane
0.004 (0,10)
0.012 (0,30)
0.004 (0,10)
0.104 (2,65) MAX
PINS **
16
20
24
28
0.710
DIM
0.410
0.510
0.610
A MAX
A MIN
(10,41) (12,95) (15,49) (18,03)
0.400
0.500
0.600
0.700
(10,16) (12,70) (15,24) (17,78)
4040000/D 01/00
NOTES: A. All linear dimensions are in inches (millimeters).
B. This drawing is subject to change without notice.
C. Body dimensions do not include mold flash or protrusion not to exceed 0.006 (0,15).
D. Falls within JEDEC MS-013
