TAS5715
SLOS645 –AUGUST 2010
www.ti.com
PWM SHUTDOWN GROUP REGISTER (0x19)
Settings of this register determine which PWM channels are active. The value should be 0x30 for BTL mode and
0x3A for PBTL mode. The default value of this register is 0x30. The functionality of this register is tied to the
state of bit D5 in the system control register.
This register defines which channels belong to the shutdown group (SDG). If a 1 is set in the shutdown group
register, that particular channel is not started following an exit out of all-channel shutdown command (if bit D5 is
set to 0 in system control register 2, 0x05).
Table 17. Shutdown Group Register
D7
0
–
–
–
–
–
–
–
–
–
–
–
D6
–
0
–
–
–
–
–
–
–
–
–
–
D5
–
–
1
–
–
–
–
–
–
–
–
–
D4
–
–
–
1
–
–
–
–
–
–
–
–
D3
–
–
–
–
0
1
–
–
–
–
–
–
D2
–
–
–
–
–
–
0
1
–
–
–
–
D1
–
–
–
–
–
–
–
–
0
1
–
–
D0
–
–
–
–
–
–
–
–
–
–
0
1
FUNCTION
(1)
(1)
(1)
(1)
Reserved
Reserved
Reserved
Reserved
(1)
(1)
(1)
(1)
PWM channel 4 does not belong to shutdown group.
PWM channel 4 belongs to shutdown group.
PWM channel 3 does not belong to shutdown group.
PWM channel 3 belongs to shutdown group.
PWM channel 2 does not belong to shutdown group.
PWM channel 2 belongs to shutdown group.
PWM channel 1 does not belong to shutdown group.
PWM channel 1 belongs to shutdown group.
(1) Default values are in bold.
