Shutdown Sequence
Enter:
1. Write 0x40 to register 0x05.
2. Wait at least 1 ms + 1.3 × tstop (where tstop is specified by register 0x1A).
3. If desired, reconfigure by returning to step 4 of initialization sequence.
Exit:
1. Write 0x00 to register 0x05 (exit shutdown command may not be serviced for as much as 240 ms
after trim following AVDD/DVDD power-up ramp).
2. Wait at least 1 ms + 1.3 × tstart (where tstart is specified by register 0x1A).
3. Proceed with normal operation.
Power-Down Sequence
Use the following sequence to power down the device and its supplies:
1. If time permits, enter shutdown (sequence defined above); else, in case of sudden power loss,
assert PDN = 0 and wait at least 2 ms.
2. Assert RESET = 0.
3. Drive digital inputs low and ramp down PVDD supply as follows:
•
•
Drive all digital inputs low after RESET has been low for at least 2 µs.
Ramp down PVDD while ensuring that it remains above 8 V until RESET has been low for at
least 2 µs.
4. Ramp down AVDD/DVDD while ensuring that it remains above 3 V until PVDD is below 6 V and
that it is never more than 2.5 V below the digital inputs.
