Introduction
1.1 TAS5622-TAS5624DDVEVM Features
•
•
Stereo PurePath Digital™ evaluation module.
Self-contained protection system (overcurrent, overtemperature, undervoltage and missing PWM
input).
•
•
Standard I2S and I2C™ / Control connector for TI input board
Double-sided plated-through PCB layout.
8 Channel
Analog
Input
Control Interface
Stereo/Mono
Channel
Speaker Output
TAS5622-TAS5624DDVEVM
USB
Interface
I2C Bus
I2S Bus
Optical
and
Coaxial
S/PDIF
Input
Example:
TI Input - USB Board 3
Power Supply
Figure 3. Integrated PurePath Digital™ Amplifier System
1.2 EVM Physical Structure
Physical structure of the TAS5622-TAS5624DDVEVM is illustrated in Figure 4.
