SN65HVD72
SN65HVD75
SN65HVD78
SLLSE11B –MARCH 2012–REVISED JUNE 2012
www.ti.com
REVISION HISTORY
Changes from Original (March 2012) to Revision A
Page
•
•
Changed the Switching Characteristics condition statement From: 15 kbps devices (HVD73, 74, 75) bit time > 65 ns
To: 20 Mbps devices (HVD73, 74, 75) bit time > 50 ns ....................................................................................................... 5
Changed the Switching Characteristics condition statement From: 50 kbps devices (HVD76, 77, 78) bit time > 20 ns
To: 50 Mbps devices (HVD76, 77, 78) bit time > 20 ns ....................................................................................................... 6
•
•
•
•
•
•
•
•
Added Figure 12 to TYPICAL CHARACTERISTICS. ......................................................................................................... 10
Added Figure 13 to TYPICAL CHARACTERISTICS. ......................................................................................................... 11
Added Figure 14 to TYPICAL CHARACTERISTICS. ......................................................................................................... 11
Added Figure 15 to TYPICAL CHARACTERISTICS. ......................................................................................................... 11
Added Figure 16 to TYPICAL CHARACTERISTICS. ......................................................................................................... 11
Added Figure 17 to TYPICAL CHARACTERISTICS. ......................................................................................................... 12
Added VALUEs to the Thermal Characteristics table in the DEVICE INFORMATION section. ......................................... 12
Added APPLICATION INFORMATION section to data sheet. ........................................................................................... 14
Changes from Original (May 2012) to Revision B
Page
•
•
•
•
•
Added the SON-8 package and Nodes column to Table 1, ................................................................................................. 1
Changed the SN65HVD72, 75, 78 Logic Diagram ............................................................................................................... 1
Changed the Voltage range at A or B Inputs MIN value From: –8 V To: –13 V .................................................................. 3
Added foot note for free-air temperature to the RECOMMENDED OPERATING CONDITIONS table ............................... 3
Changed the Bus input current (disabled driver) TYP values for HVD78 VI = 12 V From: 150 To: 240 and VI = –7 V
From: –120 To: –180 ............................................................................................................................................................ 4
•
•
•
•
•
Added TYP values to the SWITCHING CHARACTERISTICS table .................................................................................... 5
Added TYP values to the SWITCHING CHARACTERISTICS table .................................................................................... 6
Changed Table 4, Thermal Information .............................................................................................................................. 12
Changed Table 5, Thermal Characteristics ........................................................................................................................ 12
Added section: LOW-POWER STANDBY MODE .............................................................................................................. 13
