PACKAGE MATERIALS INFORMATION
www.ti.com
3-Jun-2022
TAPE AND REEL INFORMATION
REEL DIMENSIONS
TAPE DIMENSIONS
K0
P1
W
B0
Reel
Diameter
Cavity
A0
A0 Dimension designed to accommodate the component width
B0 Dimension designed to accommodate the component length
K0 Dimension designed to accommodate the component thickness
Overall width of the carrier tape
W
P1 Pitch between successive cavity centers
Reel Width (W1)
QUADRANT ASSIGNMENTS FOR PIN 1 ORIENTATION IN TAPE
Sprocket Holes
Q1 Q2
Q3 Q4
Q1 Q2
Q3 Q4
User Direction of Feed
Pocket Quadrants
*All dimensions are nominal
Device
Package Package Pins
Type Drawing
SPQ
Reel
Reel
A0
B0
K0
P1
W
Pin1
Diameter Width (mm) (mm) (mm) (mm) (mm) Quadrant
(mm) W1 (mm)
PCM1794ADBR
PCM1794ADBR
SSOP
SSOP
DB
DB
28
28
2000
2000
330.0
330.0
16.4
17.4
8.2
8.5
10.5
10.8
2.5
2.4
12.0
12.0
16.0
16.0
Q1
Q1
Pack Materials-Page 1
