PACKAGE OUTLINE
DB0028A
SSOP - 2 mm max height
S
C
A
L
E
1
.
5
0
0
SMALL OUTLINE PACKAGE
C
8.2
7.4
TYP
A
0.1 C
SEATING
PIN 1 INDEX AREA
PLANE
26X 0.65
28
1
2X
10.5
9.9
8.45
NOTE 3
14
15
0.38
0.22
28X
0.15
C A B
5.6
5.0
B
NOTE 4
2 MAX
0.25
GAGE PLANE
(0.15) TYP
SEE DETAIL A
0.95
0.55
0.05 MIN
0 -8
A
15
DETAIL A
TYPICAL
4214853/B 03/2018
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not
exceed 0.15 mm per side.
4. This dimension does not include interlead flash. Interlead flash shall not exceed 0.25 mm per side.
5. Reference JEDEC registration MO-150.
www.ti.com
TI [ TEXAS INSTRUMENTS ]
