9.7 Header Type and BIST Register
The header type and built-in self-test (BIST) register indicates the Smart Card controller PCI header type and no
built-in self-test. See Table 9−6 for a complete description of the register contents.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Header type and BIST
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
x
R
0
R
0
R
0
R
0
R
0
R
0
R
0
Register:
Offset:
Type:
Header type and BIST
0Eh
Read-only
00x0h
Default:
Table 9−6. Header Type and BIST Register Description
BIT
FIELD NAME
TYPE
DESCRIPTION
15−8
BIST
R
Built-in self-test. The Smart Card controller does not include a BIST; therefore, this field returns 00h
when read.
7−0
HEADER_TYPE
R
PCI header type. The Smart Card controller includes the standard PCI header. Bit 7 indicates if the Smart
Card is a multifunction device.
9.8 Smart Card Base Address Register 0
This register is used by this function to determine where to forward a memory transaction to the Smart Card global
control register set. Bits 31−12 of this register are read/write and allow the base address to be located anywhere in
the 32-bit PCI memory space on 4-Kbyte boundary. The window size is always 4K bytes. Bits 11−0 are read-only and
always return 0s. Write transactions to these bits have no effect. Bit 3 (0b) specifies that this window is
nonprefetchable. Bits 2−1 (00b) specify that this memory window can allocate anywhere in the 32-bit address space.
Bit
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Name
Type
Default
Bit
Smart Card base address register 0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Smart Card base address register 0
RW
0
RW
0
RW
0
RW
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
Register:
Offset:
Type:
Smart Card base address register 0
10h
Read/Write, Read-only
0000 0000h
Default:
9−6
