9.4 Status Register
The status register provides device information to the host system. All bit functions adhere to the definitions in the
PCI Local Bus Specification, as seen in the following bit descriptions. Bits in this register may be read normally. A
bit in the status register is reset when a 1 is written to that bit location; a 0 written to a bit location has no effect. See
Table 9−3 for a complete description of the register contents.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Status
RCU RCU
R
0
R
0
RCU
0
R
0
R
1
R
0
R
0
R
0
R
0
R
1
RU
0
R
0
R
0
R
0
0
0
Register:
Offset:
Type:
Status
06h
Read/Clear/Update, Read-only
0210h
Default:
Table 9−3. Status Register Description
BIT
15
FIELD NAME
PAR_ERR
TYPE
RCU
RCU
DESCRIPTION
Detected parity error. Bit 15 is set to 1 when either an address parity or data parity error is detected.
14
SYS_ERR
Signaled system error. Bit 14 is set to 1 when SERR is enabled and the Smart Card controller has
signaled a system error to the host.
13
12
MABORT
R
R
This function does not support bus mastering. This bit is hardwired to 0.
TABT_REC
This function does not support bus mastering and never receives a target abort. This bit is hardwired
to 0.
11
TABT_SIG
RCU
R
Signaled target abort. Bit 11 is set to 1 by the Smart Card controller when it terminates a transaction
on the PCI bus with a target abort.
10−9
PCI_SPEED
DEVSEL timing. Bits 10 and 9 encode the timing of DEVSEL and are hardwired to 01b, indicating that
the Smart Card controller asserts this signal at a medium speed on nonconfiguration cycle accesses.
8
7
DATAPAR
FBB_CAP
R
R
This function does not support bus mastering. This bit is hardwired to 0.
Fast back-to-back capable. The Smart Card controller cannot accept fast back-to-back transactions;
therefore, bit 7 is hardwired to 0.
6
5
RSVD
R
R
Reserved. Bit 6 returns 0 when read.
66MHZ
66-MHz capable. The Smart Card controller operates at a maximum PCLK frequency of 33 MHz;
therefore, bit 5 is hardwired to 0.
4
3
CAPLIST
INT_STAT
R
Capabilities list. Bit 4 returns 1 when read, indicating that the Smart Card controller supports additional
PCI capabilities. The linked list of PCI power-management capabilities is implemented in this function.
RU
Interrupt status. This bit reflects the interrupt status of the function. Only when bit 10 (INT_DISABLE)
in the command register (see Section 7.3) is a 0 and this bit is 1, is the function’s INTx signal asserted.
Setting the INT_DISABLE bit to 1 has no effect on the state of this bit. This bit is set only when a valid
interrupt condition exists. This bit is not set when an interrupt condition exists and signaling of that event
is not enabled.
2−0
RSVD
R
Reserved. Bits 3−0 return 0s when read.
9−4
