OPA171
OPA2171
OPA4171
www.ti.com
SBOS516C –SEPTEMBER 2010–REVISED JUNE 2011
REVISION HISTORY
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Revision B (November 2010) to Revision C
Page
•
•
•
•
•
•
•
Added MSOP-8 package to device graphic .......................................................................................................................... 1
Added MSOP-8 package to Features bullets ....................................................................................................................... 1
Added MSOP-8 package to Product Family table ................................................................................................................ 1
Added MSOP-8 package to Package/Ordering Information table ........................................................................................ 2
Deleted "A" suffix from OPA4171 package markings in Package/Ordering Information table. ............................................ 2
Added new row for Voltage Output Swing from Rail parameter to Output subsection of Electrical Characteristics ............ 3
Changed Voltage Output Swing from Rail parameter to over temperature in Output subsection of Electrical
Characteristics ...................................................................................................................................................................... 3
•
•
•
•
Updated format of thermal information tables ...................................................................................................................... 4
Added MSOP-8 package to OPA2171 Thermal Information table ....................................................................................... 4
Updated pinout configurations for OPA2171 and OPA4171 ................................................................................................ 5
Changed Figure 9 ................................................................................................................................................................. 8
Changes from Revision A (November, 2010) to Revision B
Page
•
•
•
Changed input offset voltage specification ........................................................................................................................... 3
Changed input offset voltage, over temperature specification .............................................................................................. 3
Changed quiescent current per amplifier, over temperature specification ........................................................................... 3
Copyright © 2010–2011, Texas Instruments Incorporated
15
TI [ TEXAS INSTRUMENTS ]
