LM5116
www.ti.com
SNVS499G –FEBRUARY 2007–REVISED MARCH 2013
Electrical Characteristics (continued)
Limits in standard type are for TJ = 25°C only; limits in boldface type apply over the junction temperature range of -40°C to
+125°C and are provided for reference only. Unless otherwise specified, the following conditions apply: VIN = 48V, VCC =
7.4V, VCCX = 0V, EN = 5V, RT = 16 kΩ, no load on LO and HO.
Symbol
Parameter
Conditions
Min
Typ
Max
Units
Switching Characteristics
LO Fall to HO Rise Delay
HO Fall to LO Rise Delay
C-load = 0
C-load = 0
75
70
ns
ns
Thermal
TSD
Thermal Shutdown
Rising
170
15
40
4
°C
°C
Thermal Shutdown Hysteresis
Junction to Ambient
Junction to Case
θJA
θJC
°C/W
°C/W
Copyright © 2007–2013, Texas Instruments Incorporated
Submit Documentation Feedback
7
Product Folder Links: LM5116
