LM3886
www.ti.com
SNAS091C –MAY 1999–REVISED MARCH 2013
These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam
during storage or handling to prevent electrostatic damage to the MOS gates.
(1)(2)(3)
Absolute Maximum Ratings
Supply Voltage |V+|+|V−|
Supply Voltage |V+|+|V−|
Common Mode Input Voltage
(No Signal)
94V
84V
(Input Signal)
(V+ or V−) and
|V+| + |V−| ≤ 80V
(4)
Differential Input Voltage
60V
Internally Limited
125W
Output Current
(5)
Power Dissipation
(6)
ESD Susceptibility
3000V
(7)
Junction Temperature
150°C
Soldering Information
Storage Temperature
Thermal Resistance
T Package (10 seconds)
260°C
−40°C to +150°C
1°C/W
θJC
θJA
43°C/W
(1) All voltages are measured with respect to the GND pin (pin 7), unless otherwise specified.
(2) Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for
which the device is functional. Electrical Characteristics state DC and AC electrical specifications under particular test conditions and
specific performance limits. This assumes that the device is within the Operating Ratings. The typical value is a good indication of
device performance.
(3) If Military/Aerospace specified devices are required, please contact the Texas Instruments Sales Office/ Distributors for availability and
specifications.
(4) The Differential Input Voltage Absolute Maximum Rating is based on supply voltages of V+ = +40V and V− = −40V.
(5) For operating at case temperatures above 25°C, the device must be derated based on a 150°C maximum junction temperature and a
thermal resistance of θJC = 1.0 °C/W (junction to case). Refer to Figure 50 in Application Information under THERMAL
CONSIDERATIONS.
(6) Human body model, 100 pF discharged through a 1.5 kΩ resistor.
(7) The operating junction temperature maximum is 150°C, however, the instantaneous Safe Operating Area temperature is 250°C.
(1)(2)(3)
Operating Ratings
Temperature Range
TMIN ≤ TA ≤ TMAX
−20°C ≤ TA ≤ +85°C
Supply Voltage |V+| + |V−|
20V to 84V
(1) All voltages are measured with respect to the GND pin (pin 7), unless otherwise specified.
(2) Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for
which the device is functional. Electrical Characteristics state DC and AC electrical specifications under particular test conditions and
specific performance limits. This assumes that the device is within the Operating Ratings. The typical value is a good indication of
device performance.
(3) Operation is specified up to 84V, however, distortion may be introduced from SPIKe Protection Circuitry if proper thermal considerations
are not taken into account. Refer to THERMAL CONSIDERATIONS for more information. (See Figure 5)
