SNVS124C – NOVEMBER 1999 – REVISED APRIL 2013
Table 2. Output Capacitor and Feedforward Capacitor Selection Table (continued)
Output
Voltage
(V)
9
12
15
24
28
Through Hole Output Capacitor
Panasonic
HFQ Series
(μF/V)
330/25
330/25
220/35
220/35
100/50
Nichicon PL
Series
(μF/V)
330/25
330/25
220/35
150/35
100/50
Feedforward
Capacitor
1.5 nF
1 nF
680 pF
560 pF
390 pF
Surface Mount Output Capacitor
AVX TPS
Series
(μF/V)
100/16
100/16
68/20
33/25
10/35
Sprague
595D Series
(μF/V)
180/16
180/16
120/20
33/25
15/50
Feedforward
Capacitor
1.5 nF
1 nF
680 pF
220 pF
220 pF
LM2596 Series Buck Regulator Design Procedure
INDUCTOR VALUE SELECTION GUIDES
(For Continuous Mode Operation)
Figure 21. LM2596-3.3
Figure 22. LM2596-5.0
Figure 23. LM2596-12
Figure 24. LM2596-ADJ
Copyright © 1999–2013, Texas Instruments Incorporated
Product Folder Links:
15
