DS75176B, DS75176BT
www.ti.com
SNLS381C –JULY 1998–REVISED APRIL 2013
Note: Differential input voltage may may be realized by grounding RI and pulsing RI between +2.5V and −2.5V
Figure 8. Receiver Propagation Delays
Figure 9. Receiver Enable and Disable Times
Table 1. DS75176B Transmitting(1)
Function Tables
Inputs
Line Condition
Outputs
RE
X
DE
1
DI
1
DO
DO
1
No Fault
No Fault
X
0
1
Z
Z
X
1
0
0
X
0
X
X
Z
X
1
Fault
Z
(1) X — Don't care condition
Z — High impedance state
Fault — Improper line conditons causing excessive power dissipation
in the driver, such as shorts or bus contention situations
**This is a fail safe condition
