DM385, DM388
www.ti.com
SPRS821D –MARCH 2013–REVISED DECEMBER 2013
Table 3-20. GPMC Terminal Functions (continued)
SIGNAL NAME [1]
DESCRIPTION [2]
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Multiplexed Data/Address I/O
GPMC Output Enable output
TYPE [3]
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
O
AAR BALL [4]
GPMC_D[4]
GPMC_D[5]
GPMC_D[6]
GPMC_D[7]
GPMC_D[8]
GPMC_D[9]
GPMC_D[10]
GPMC_D[11]
GPMC_D[12]
GPMC_D[13]
GPMC_D[14]
GPMC_D[15]
W9
T5
T3
T2
T1
T8
R6
R4
R3
R2
R1
P2
Y8
W8
GPMC_OE_RE
GPMC_WAIT[0]
GPMC_WAIT[1]
GPMC_WE
GPMC Wait input 0
I
GPMC Wait input 1
I
AB9
Y5
GPMC Write Enable output
O
