CC2510Fx / CC2511Fx
3
Absolute Maximum Ratings
Under no circumstances must the absolute maximum ratings given in Table 2 be violated. Stress
exceeding one or more of the limiting values may cause permanent damage to the device.
Parameter
Min
Max
Units Condition
Supply voltage (VDD)
Voltage on any digital pin
−0.3
3.9
V
V
All supply pins must have the same voltage
−0.3 VDD + 0.3,
max 3.9
Voltage on the pins RF_P, RF_N
and DCOUPL
−0.3
−50
2.0
V
Voltage ramp-up rate
Input RF level
120
10
kV/µs
dBm
°C
Storage temperature range
Solder reflow temperature
150
260
750
Device not programmed
According to IPC/JEDEC J-STD-020D
°C
V
According to JEDEC STD 22, method A114, Human
Body Model (HBM)
ESD CC2510Fx
ESD CC2510Fx
ESD CC2511x
ESD CC2511x
500
750
500
V
V
V
According to JEDEC STD 22, C101C, Charged Device
Model (CDM)
According to JEDEC STD 22, method A114, Human
Body Model (HBM)
According to JEDEC STD 22, C101C, Charged Device
Model (CDM)
Table 2: Absolute Maximum Ratings
Caution!
ESD
sensitive
device.
Precaution should be used when handling
the device in order to prevent permanent
damage.
SWRS055F
Page 8 of 241
