CC1110Fx / CC1111Fx
P0DIRPort 0 Direction
P1DIRPort 1 Direction
P2DIRPort 2 Direction
P0INPPort 0 Input Mode
P1INPPort 1 Input Mode
P2INPPort 2 Input Mode
P0IFGPort 0 Interrupt Status Flag
P1IFGPort 1 Interrupt Status Flag
P2IFGPort 2 Interrupt Status Flag
PICTLPort Interrupt Control
P1IENPort 1 Interrupt Mask
P0 (0x80) - Port 0
Bit
Field Name
Reset
R/W
Description
7:0
P0[7:0]
0xFF
R/W
Port 0. General purpose I/O port. Bit-addressable.
P1 (0x90) - Port 1
Bit
Field Name
Reset
R/W
Description
7:0
P1[7:0]
0xFF
R/W
Port 1. General purpose I/O port. Bit-addressable.
P2 (0xA0) - Port 2
Bit
7:5
4:0
Field Name
Reset
111
R/W
R/W
R/W
Description
Not used
P2[4:0]
11111
Port 2. General purpose I/O port. Bit-addressable.
PERCFG (0xF1) - Peripheral Control
Bit
7
Field Name
Reset
R/W
R0
Description
0
0
Not used
6
T1CFG
R/W
Timer 1 I/O location
0
1
Alternative 1 location
Alternative 2 location
5
4
T3CFG
T4CFG
0
0
R/W
R/W
Timer 3 I/O location
0
1
Alternative 1 location
Alternative 2 location
Timer 4 I/O location
0
1
Alternative 1 location
Alternative 2 location
3:2
1
00
0
R0
Not used
U1CFG
U0CFG
R/W
USART1 I/O location
0
1
Alternative 1 location
Alternative 2 location
0
0
R/W
USART0 I/O location
0
1
Alternative 1 location
Alternative 2 location
SWRS033H
Page 95 of 246
