CC1110Fx / CC1111Fx
asserted when the event occurs. If the
corresponding mask bit is set in the RFIM
register, the CPU interrupt flag S1CON.RFIF
will also be asserted in addition to the interrupt
flag in RFIF. If IEN2.RFIE=1 when
S1CON.RFIF is asserted, and interrupt
request will be generated.
CS
PQT reached
CCA
SFD
Each of these events has a corresponding
interrupt flag in the RFIF register which is
Refer to 0 for details about the interrupts.
RFIF (0xE9) - RF Interrupt Flags
Bit
Field Name
Reset
R/W
Description
7
IRQ_TXUNF
0
R/W0
TX underflow
0
1
No interrupt pending
Interrupt pending
6
5
4
IRQ_RXOVF
IRQ_TIMEOUT
IRQ_DONE
0
0
0
R/W0
R/W0
R/W0
RX overflow
0
1
No interrupt pending
Interrupt pending
RX timeout, no packet has been received in the programmed period
0
1
No interrupt pending
Interrupt pending
Packet received/transmitted. Also used to detect underflow/overflow
conditions
0
1
No interrupt pending
Interrupt pending
3
2
1
0
IRQ_CS
0
0
0
0
R/W0
R/W0
R/W0
R/W0
Carrier sense
0
1
No interrupt pending
Interrupt pending
IRQ_PQT
IRQ_CCA
IRQ_SFD
Preamble quality threshold reached
0
1
No interrupt pending
Interrupt pending
Clear Channel Assessment
0
1
No interrupt pending
Interrupt pending
Start of Frame Delimiter, sync word detected
0
1
No interrupt pending
Interrupt pending
SWRS033H
Page 189 of 246
