3.4 External Capacitors
To improve module performance, decoupling capacitors are required to suppress the switching noise generated
by high frequency and to stabilize the supply voltage. A decoupling capacitor is most effective when it is close to
the device, because this minimizes the inductance of the circuit board wiring and interconnects.
3.4.1 Voltage Decoupling Capacitors
Table 3-14 summarizes the Core voltage decoupling characteristics.
3.4.1.1 Core Voltage Decoupling Capacitors
To improve module performance, decoupling capacitors are required to suppress high-frequency switching noise
and to stabilize the supply voltage. A decoupling capacitor is most effective when located close to the AM335x
device, because this minimizes the inductance of the circuit board wiring and interconnects.
Table 3-14. Core Voltage Decoupling Characteristics
PARAMETER
TYP
10.08
10.05
UNIT
μF
(1)
CVDD_CORE
(2)(3)
CVDD_MPU
μF
(1) The typical value corresponds to 1 cap of 10 μF and 8 caps of 10 nF.
(2) Not available on the ZCE package. VDD_MPU is merged with VDD_CORE on the ZCE package.
(3) The typical value corresponds to 1 cap of 10 μF and 5 caps of 10 nF.
