73S1215F Data Sheet
DS_1215F_003
3.4 Oscillator Interface Requirements
Symbol
Parameter
Condition
Min
Typ.
Max
Unit
Low-Power Oscillator Requirements. No External Load Beside The Crystal And Capacitor Is
Permitted On Xout32.
Pxtal
IIL
Power In Crystal
1
Μw
GND < Vin < VDD
Input Leakage Current
-5
5
Μa
High-Frequency Oscillator (Xin) Parameters. XIN Is Used As Input For External Clock For Test
Purposes Only. A Resistor Connecting X12in To X12out Is Required, Value = 1MΩ.
VILX12IN
Input Low Voltage –
X12IN
-0.3
0.3*VDD
Vdd+.0.3
V
V
Input High Voltage – X12IN
Input Current –
X12IN
VIHX12IN
IILXTAL
0.7*VDD
GND < Vin < Vdd
-10
6
10
12
Μa
Fxtal
Crystal Resonant
Frequency
Fundamental
Mode
Mhz
3.5 DC Characteristics: Analog Input
Symbol
Parameter
Condition
Min
Typ.
Max
Unit
VTHTOL
Voltage Threshold
Tolerance
Selected Threshold
Value
-3%
+3%
V
114
Rev. 1.4
