73S1215F Data Sheet
DS_1215F_003
3 Electrical Specification
3.1 Absolute Maximum Ratings
Operation outside these rating limits may cause permanent damage to the device. The smart card
interface pins are protected against short circuits to VCC, ground, and each other.
Parameter
Rating
DC Supply voltage, VDD
Supply Voltage VPC
-0.5 to 4.0 VDC
-0.5 to 6.5 VDC
Storage Temperature
-60 to 150°C
Pin Voltage (except card interface)
Pin Voltage (card interface)
ESD tolerance (except card interface)
ESD tolerance (card interface)
Pin Current
-0.3 to (VDD+0.5) VDC
-0.3 to (VCC+0.5) VDC
+/- 2KV
+/- 6KV
± 200 mA
Note: ESD testing on smart card pins is HBM condition, 3 pulses, each polarity referenced to ground.
Note: Smart Card pins are protected against shorts between any combinations of Smart Card pins.
3.2 Recommended Operating Conditions
Unless otherwise noted all specifications are valid over these temperatures and supply voltage ranges:
Parameter
Rating
DC Voltage Supply VDD
2.7 to 3.6 VDC
3.0 to 3.6 VDC
4.75 to 6.0 VDC
DC Voltage Supply VDD for USB operation
Supply Voltage VPC for Class A-B-C Reader
Ambient Operating Temperature (Ta)
-40°C to +85°C
112
Rev. 1.4
