71M6521DE/71M6521FE
Energy Meter IC
DATASHEET
JANUARY 2008
ELECTRICAL SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Supplies and Ground Pins:
V3P3SYS, V3P3A
VBAT
−0.5V to 4.6V
-0.5V to 4.6V
-0.5V to +0.5V
GNDD
Analog Output Pins:
-10mA to 10mA,
-0.5V to 4.6V
-10mA to +10mA,
-0.5V to V3P3A+0.5V
-10mA to +10mA,
-0.5V to 3.0V
V3P3D
VREF
V2P5
Analog Input Pins:
IA, VA, IB, VB, V1
-10mA to +10mA
-0.5V to V3P3A+0.5V
-10mA to +10mA
-0.5V to 3.0V
XIN, XOUT
All Other Pins:
-1mA to +1mA,
Configured as SEG or COM drivers
-0.5 to V3P3D+0.5
-10mA to +10mA,
-0.5 to 6V
Configured as Digital Inputs
-15mA to +15mA,
-0.5V to V3P3D+0.5V
−0.5V to V3P3D+0.5V
Configured as Digital Outputs
All other pins
Operating junction temperature (peak, 100ms)
Operating junction temperature (continuous)
Storage temperature
Solder temperature – 10 second duration
ESD stress on all pins
140 °C
125 °C
−45 °C to +165 °C
250 °C
4kV
Stresses beyond Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings only and functional
operation at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure
to absolute-maximum-rated conditions for extended periods may affect device reliability. All voltages are with respect to GNDA.
