Application Notes
AN1010
Ballast
3.3 µF
MT2
MT1
470 k
47 k
240 V ac
Line
Input
Q601E4
G
0.047 µF
50 V
1N4004
HT-32
Lamp
40 W
Optional
Charging
Network
Figure AN1010.4
240 V ac Triac/Diac Circuit
Figure AN1010.5 illustrates a circuit using a sidac phase control
network to ignite a 240 V ac fluorescent lamp. This circuit works
basically the same as the 120 V circuit shown in Figure
pensate for higher voltage. The one major change is that two
K2400E devices in series are used to accomplish high firing volt-
age for a fluorescent lamp.
AN1010.3, except that component values are changed to com-
Ballast
3.3 µF
K2400E
Sidac
47 k
240 V ac
Line
Input
K2400E
Sidac
1N4004
Lamp
40 W
Optional
Charging
Network
Figure AN1010.5
240 V ac Sidac Circuit
©2002 Teccor Electronics
Thyristor Product Catalog
AN1010 - 3
http://www.teccor.com
+1 972-580-7777
