High Surge Current SIDACtor Device
High Surge Current SIDACtor Device
This SIDACtor device is a 1000 A solid state protection device offered in a TO-220 package.
1
(T)
It protects equipment located in the severe surge environment of Community Antenna TV
2
(G)
(CATV) applications.
3
(R)
This device can replace the gas tubes traditionally used for station protection because
SIDACtor devices have much tighter voltage tolerances.
Electrical Parameters
CO
pF
Pins 1-3
Part
VDRM
Volts
VS
VT
IDRM
IS
IT
IH
Number *
Volts
Volts
µAmps
mAmps
Amps
mAmps
P6002AD
550
700
5.5
5
800
2.2
50
60
* For surge ratings, see table below.
Electrical Parameters
CO
pF
Pins 1-3
Part
VDRM
Volts
VS
VT
IDRM
IS
IT
IH
Number *
Volts
Volts
µAmps
mAmps
Amps
mAmps
P3100AD
280
360
5.5
5
800
2.2
120
115
* For surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias and is a typical value.
Surge Ratings
IPP
IPP
ITSM
60 Hz
Amps
8x20 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps/µs
D
1000
250
120
1000
http://www.teccor.com
+1 972-580-7777
2 - 62
© 2002 Teccor Electronics
®
SIDACtor Data Book and Design Guide
