CATV and HFC SIDACtor Device
CATV and HFC SIDACtor Device
This SIDACtor device is a 1000 A solid state protection device offered in a TO-220 package.
It protects equipment located in the severe surge environment of Community Antenna TV
(CATV) applications.
1
3
Used in Hybrid Fiber Coax (HFC) applications, this device replaces the gas tube
traditionally used for station protection, because a SIDACtor device has a much tighter
voltage tolerance.
Electrical Parameters
CO
pF
Pins 1-3
200
Part
VDRM
Volts
120
170
VS
VT
IDRM
IS
IT
IH
Number *
Volts
Volts
µAmps
mAmps
Amps
mAmps
P1400AD
P1800AD
160
220
3
5.5
5
5
800
800
2.2
2.2
50
50
150
* For surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias and is a typical value.
Surge Ratings
IPP
IPP
ITSM
60 Hz
Amps
8x20 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps/µs
D
1000
250
120
500
