Battrax Dual Negative SLIC Protector
Battrax Dual Negative SLIC Protector
This solid state Battrax protection device is referenced to a negative voltage source. Its
dual-chip package also includes internal diodes for transient protection from positive
surge events.
(G)
5
For a diagram of a Battrax application, see Figure 3.27.
1
2
3
(R)
(T) (-VREF
)
Electrical Parameters
Part
VDRM
VS
VT
VF
IDRM
IGT
IT
IH
CO
pF
Number *
Volts
Volts
Volts
Volts
µAmps
mAmps
Amps
mAmps
B1101U_
B1161U_
B1201U_
|-VREF| + |-1.2V|
|-VREF| + |-1.2V|
|-VREF| + |-1.2V|
|-VREF| + |-10V|
|-VREF| + |-10V|
|-VREF| + |-10V|
4
4
4
5
5
5
5
5
5
100
100
100
1
1
1
100
160
200
50
50
50
* For individual “UA” and “UC” surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
PP ratings assume a VREF = -48 V.
I
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Off-state capacitance is measured at 1 MHz with a 2 V bias and is a typical value. “UC” product is approximately 2x the listed value.
REF maximum value for the B1101, B1161, and/or B1201 is -200 V.
V
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
Amps
8x20 µs
Amps
10x160 µs
Amps
10x560 µs
Amps
10x1000 µs
Amps
di/dt
Series
A
C**
Amps/µs
150
500
150
400
90
200
50
120
45
100
20
50
500
500
** Call factory for release date.
