Fixed Voltage SLIC Protector
Fixed Voltage SLIC Protector
These DO-214AA unidirectional protectors are constructed with a SIDACtor device and an
(T/R)
integrated diode. They protect SLICs (Subscriber Line Interface Circuits) from damage
during transient voltage activity and enable line cards to meet various regulatory
requirements including GR 1089, ITU K.20, K.21 and K.45, IEC 60950, UL 60950, and TIA-
968 (formerly known as FCC Part 68).
(G)
For specific design criteria, see details in Figure 3.21.
Cathode
Electrical Parameters
Part
VDRM
VS
VT
VF
IDRM
IS
IT
IH
CO
pF
Number *
Volts
Volts
Volts
Volts
µAmps
mAmps
Amps
mAmps
P0641S_
P0721S_
P0901S_
P1101S_
58
65
75
95
77
88
98
4
4
4
4
5
5
5
5
5
5
5
5
800
800
800
800
1
1
1
1
120
120
120
120
70
70
70
70
130
* For individual “SA” and “SC” surge ratings, see table below.
General Notes:
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
V
DRM is measured at IDRM.
VS and VF are measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias and is a typical value for “SA” and “SB” product. “SC” capacitance is
approximately 2x the listed value.
•
Parallel capacitive loads may affect electrical parameters.
Surge Ratings (Preliminary Data)
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
Amps
8x20 µs
Amps
10x160 µs
Amps
10x560 µs
Amps
10x1000 µs
Amps
di/dt
Series
Amps/µs
A
C
150
500
150
400
90
200
50
120
45
100
20
50
500
500
