LCAS Asymmetrical Discrete Device
LCAS Asymmetrical Discrete Device
These DO-214AA SIDACtor devices are intended for LCAS (Line Circuit Access Switch)
applications that require asymmetrical protection in discrete (individual) packages. They
enable the protected equipment to meet various regulatory requirements including
GR 1089, ITU K.20, K.21, K.45, IEG 60950, UL 60950, and TIA-968.
Electrical Parameters
Part
VDRM
VS
VT
IDRM
IS
IT
IH
CO
pF
Number *
Volts
Volts
Volts
µAmps
mAmps
Amps
mAmps
P1200S_
P2000S_
P2500S_
100
180
230
130
220
290
4
4
4
5
5
5
800
800
800
2.2
2.2
2.2
120
120
120
40
30
30
* For individual “SA”, “SB”, and “SC” surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured between Pins 1-2 and 3-2 at 1 MHz with a 2 V bias and is a typical value for “SA” and “SB”
product. “SC” capacitance is approximately 10 pF higher.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
Amps
8x20 µs
Amps
10x160 µs
Amps
10x560 µs
Amps
10x1000 µs
Amps
di/dt
Series
Amps/µs
A
B
C
150
250
500
150
250
400
90
150
200
50
100
150
45
80
100
20
30
50
500
500
500
http://www.teccor.com
+1 972-580-7777
2 - 38
© 2002 Teccor Electronics
®
SIDACtor Data Book and Design Guide
