Balanced Three-chip MicroCapacitance (MC) SIDACtor Device
Balanced Three-chip MicroCapacitance (MC)
SIDACtor Device
The balanced three-chip TO-220 MC SIDACtor solid state device protects telecommunica-
tion equipment in high-speed applications that are sensitive to load values and that require
a lower capacitance. CO values for the MC are 40% lower than a standard AC part.
1
3
2
This MC SIDACtor series is used to enable equipment to meet various regulatory
requirements including GR 1089, ITU K.20, K.21, and K.45, IEC 60950, UL 60950, and
TIA-968 (formerly known as FCC Part 68) without the need of series resistors.
Electrical Parameters
VDRM
VS
VDRM
Volts
VS
Volts
Volts
Volts
Part
VT
IDRM
IS
IT
IH
CO
pF
Number *
Pins 1-2, 2-3
Pins 1-3
Volts
µAmps
mAmps
Amps
mAmps
P1553AC MC
P1803AC MC
P2103AC MC
P2353AC MC
P2703AC MC
P3203AC MC
P3403AC MC
P5103AC MC
130
150
170
200
230
270
300
420
180
210
250
270
300
350
400
600
130
150
170
200
230
270
300
420
180
210
250
270
300
350
400
600
8
8
8
8
8
8
8
8
5
5
5
5
5
5
5
5
800
800
800
800
800
800
800
800
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
150
150
150
150
150
150
150
150
40
40
40
40
30
30
30
30
* For surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured between Pins 1-2 and 3-2 at 1 MHz with a 2 V bias.
Device is designed to meet balance requirements of GTS 8700 and GR 974.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
8x20 µs
10x160 µs
10x560 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps
Amps
Amps
Amps/µs
C
500
400
200
150
100
50
500
