SIDACtor Device
SIDACtor Device
The modified TO-220 Type 61 SIDACtor solid state protection device can be used in
telecommunication protection applications that do not reference earth ground.
SIDACtor devices are used to enable equipment to meet various regulatory requirements
including GR 1089, ITU K.20, K.21 and K.45, IEC 60950, UL 60950, and TIA-968 (formerly
known as FCC Part 68).
Electrical Parameters
Part
VDRM
Volts
VS
VT
IDRM
IS
IT
IH
CO
pF
Number *
Volts
Volts
µAmps
mAmps
Amps
mAmps
P2000AA61
P2200AA61
P2400AA61
P2500AA61
P3000AA61
P3300AA61
180
200
220
240
270
300
220
240
260
290
330
360
4
4
4
4
4
4
5
5
5
5
5
5
800
800
800
800
800
800
2.2
2.2
2.2
2.2
2.2
2.2
150
150
150
150
150
150
30
30
30
30
30
30
* For surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias and is a typical value.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
0.2x310 µs
2x10 µs
8x20 µs
10x160 µs
10x560 µs
5x320 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps
Amps
Amps
Amps
Amps
Amps/µs
A
20
150
150
90
50
75
45
20
500
http://www.teccor.com
+1 972-580-7777
