Multiport Balanced SIDACtor Device
Multiport Balanced SIDACtor Device
This multiport balanced protector is a surface mount alternative to the modified TO-220
1
2
3
6
5
4
package. It is based on a six-pin surface mount SOIC package and uses Teccor’s
patented “Y” (US Patent 4,905,119) configuration. It is available in surge current ratings up
to 500 A.
SIDACtor devices are used to enable equipment to meet various regulatory requirements
including GR 1089, ITU K.20, K.21, and K.45, IEC 60950, UL 60950, and TIA-968 (formerly
known as FCC Part 68).
Electrical Parameters — Symmetrical
VDRM
VS
VDRM
VS
CO
pF
Volts
Volts
Volt
Volts
Part
VT
IDRM
IS
IT
IH
Number *
Pins 1-2, 2-3, 1-3 Pins 4-5, 5-6, 4-6
Volts
µAmps
mAmps Amps mAmps Pins 3-2, 6-5, 1-2, 4-5
P1556U_
P1806U_
P2106U_
P2356U_
P2706U_
P3206U_
P3406U_
P5106U_
130
150
170
200
230
270
300
420
180
210
250
270
300
350
400
600
130
150
170
200
230
270
300
420
180
210
250
270
300
350
400
600
8
8
8
8
8
8
8
8
5
5
5
5
5
5
5
5
800
800
800
800
800
800
800
800
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
150
150
150
150
150
150
150
150
50
50
40
40
40
40
40
40
Electrical Parameters — Asymmetrical
VDRM
VS
VDRM
Volt
VS
Volts
Volts
Volts
Part
Pins 1-2, 2-3, 4-5,
VT
IDRM
IS
IT
IH
CO
pF
Number *
5-6
Pins 4-6, 1-3
Volts
µAmps
mAmps Amps mAmps
A2106U_6
A5030U_6
170
400
250
550
50
270
80
350
3.5
3.5
5
5
800
800
2.2
2.2
120
150
40
30
* For individual “UA”, “UB”, and “UC” surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured between Pins 1-2 and 3-2 at 1 MHz with a 2 V bias and is a typical value for “UA” product. “UB”
and “UC” capacitance is approximately 10 pF higher.
•
Device is designed to meet balance requirements of GTS 8700 and GR 974.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
8x20 µs
10x160 µs
10x560 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps
Amps
Amps
Amps/µs
A
B
C
150
250
500
150
250
400
90
150
200
50
100
150
45
80
100
20
30
50
500
500
500
