MicroCapacitance (MC) SC SIDACtor Device
MicroCapacitance (MC) SC SIDACtor Device
The DO-214AA SC MC SIDACtor series is intended for applications sensitive to load
values. Typically, high speed connections require a lower capacitance. CO values for the
MicroCapacitance device are 40% lower than a standard SC part.
This MC SIDACtor series is used to enable equipment to meet various regulatory
requirements including GR 1089, IEC 60950, UL 60950, and TIA-968 (formerly known as
FCC Part 68). Contact factory regarding ITU K.20, K.21, and K.45.
Electrical Parameters
Part
VDRM
VS
VT
IDRM
IS
IT
IH
CO
pF
Number *
Volts
Volts
Volts
µAmps
mAmps
Amps
mAmps
P0080SC MC **
P0300SC MC **
P0640SC MC
P0720SC MC
P0900SC MC
P1100SC MC
P1300SC MC
P1500SC MC
P1800SC MC
P2300SC MC
P2600SC MC
P3100SC MC
P3500SC MC
6
25
58
65
75
90
120
140
170
190
220
275
320
25
40
77
88
98
130
160
180
220
260
300
350
400
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
5
5
800
800
800
800
800
800
800
800
800
800
800
800
800
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
50
50
55
35
60
60
60
50
50
50
40
40
40
40
40
150
150
150
150
150
150
150
150
150
150
150
* For surge ratings, see table below.
** Contact factory for release date.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
Amps
8x20 µs
Amps
10x160 µs
Amps
10x560 µs
Amps
10x1000 µs
Amps
di/dt
Series
Amps/µs
C
500
400
200
150
100
30
500
http://www.teccor.com
+1 972-580-7777
2 - 6
© 2002 Teccor Electronics
®
SIDACtor Data Book and Design Guide
