Document Number: PS-MPU-6500A-01
Revision: 1.1
Release Date: 03/05/2014
MPU-6500 Product Specification
8
Assembly
This section provides general guidelines for assembling InvenSense Micro Electro-Mechanical Systems
(MEMS) gyros packaged in Quad Flat No leads package (QFN) surface mount integrated circuits.
8.1
Orientation of Axes
The diagram below shows the orientation of the axes of sensitivity and the polarity of rotation. Note the pin 1
identifier (•) in the figure.
+Z
+Y
+Z
MPU
+Y
-
6500
+X
+X
Figure 14: Orientation of Axes of Sensitivity and Polarity of Rotation
36 of 40
