ICS-40180
PIN CONFIGURATION AND FUNCTION DESCRIPTIONS
3
GND
GND
4
5
2
GND
VDD
OUTPUT
1
Figure 2. Pin Configuration
Top View (Terminal Side Down)
Not to Scale
TABLE 4. PIN FUNCTION DESCRIPTIONS
PIN NAME
FUNCTION
Analog Output Signal
Ground
1
2
3
OUTPUT
GND
GND
Ground
4
5
GND
VDD
Ground
Power Supply
